MÔ TẢ SẢN PHẨM
Capacity | 500GB, 1TB, 2TB |
Form Factor | M.2 Type 2280-S2-M |
Interface | PCI Express® Base Specification Revision 3.1a (PCIe®) |
Flash Memory type | BiCS FLASH™ TLC |
Interface Maximum Speed | 32 GT/s (PCIe® Gen3x4) |
Dimension (Max: LxWxH) | 80.15 x 22.15 x 2.23 mm |
Interface Command | NVM Express™ Revision 1.3c command set |
Weight | 500GB, 1TB: 6.8 g (typ.)<br>2TB: 7.1 g (typ.) |
Performance | |
Max Sequential Read Speed*1 | 2,100 MB/s |
Max Sequential Write Speed*1 | 1,700 MB/s |
Max Random Read Speed*2 | 500GB, 1TB: 400,000 IOPS<br>2TB: 360,000 IOPS |
Max Random Write Speed*2 | 400,000 IOPS |
Endurance: TBW*3 | 50GB: 200 TB<br>1TB: 400 TB<br>2TB: 800 TB |
MTTF | 1.5 million hours |
Operating environment / protection performance | |
Operating Temperature | 0 ℃ (Ta) to 85 ℃ (Tc) |
Storage Temperature | -40 ℃ to 85 ℃ |
Shock Resistance | 9.806 km/s2 {1,000 G} 0.5 ms half sine wave |
Vibration | 196 m/s2 {20 G} Peak, 10~2,000 Hz, (20 min / Axis) x 3 Axis |
Supply Voltage | 3.3 V ±5 % |
Power Consumption | PS3: 50 mW (typ.)<br>PS4: 5 mW (typ.) |
Power Consumption (Active) | 500GB, 1TB: 3.5 W (typ.)<br>2TB: 5.3 W (typ.) |
Compatibility | |
PCI Express | Compatible with PCI Express® Base Specification Revision 3.1a and NVM Express™ Revision 1.3c command set |
Connector Type | M.2 M key Socket |
Target Applications | Client desktops and laptops |
