BẢNG THÔNG SỐ CHI TIẾT:
Camera | |
Image Sensor | 1/2.8 inch CMOS |
Max. Resolution | 1920 (H) × 1080 (V) |
ROM | 16 MB |
RAM | 64 MB |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual 1/3 s–1/100000 s |
Min. Illumination | 0.01 Lux @F2.0 |
S/N Ratio | >56 dB |
Illumination Distance | 30 m (98.4 ft) |
Illuminator On/Off Control | Auto/Manual |
Illuminator Number | 1 (IR LED) |
Pan/Tilt/Rotation Range | Pan: 0° to 360°; Tilt: 0° to 90°; Rotation: 0° to 360° |
Lens | |
Lens Type | Fixed-focal |
Lens Mount | M12 |
Focal Length | 2.8 mm; 3.6 mm |
Max. Aperture | 2.8 mm: F2.0 |
3.6 mm: F2.0 | |
Field of View | 2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120° |
3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100° | |
Iris Control | Fixed |
Video | |
Video Compression | H.265; H.264; H.264B; MJPEG (only supported by the sub stream) |
Smart Codec | Smart H.265+/Smart H.264+ |
Video Frame Rate | Main Stream: |
1920 × 1080 (1 fps–25/30 fps) | |
Sub stream: | |
704 × 576 (1 fps–25 fps) | |
704 × 480 (1 fps–30 fps) | |
Stream Capability |
